NS9210 Processor Module Hardware Reference
C h a p t e r 2
User pushbuttons,
S6 and S7
Use the user pushbuttons to interact with the applications running on the NS9210
Processor Module. Use these module signals to implement the pushbuttons:
Legend for multi-
pin switches
Switches 1 and 4 are multi-pin switches. In the description tables for these switches,
the pin is designated as S[switch number].[pin number]. For example, pin 1 in switch
4 is specified as S4.1.
Module
configuration
switches, S4
Use S4 to configure the module:
Wake-up button,
S8
The wake-up pushbutton, S8, generates an external interrupt to the module's NS9215 processor using the EIRQ2
signal.
Signal name
Switch
(pushbutton)
GPIO used
USER_PUSH_BUTTON_1
S6
GPIO81
USER_PUSH_BUTTON_2
S7
GPIO84
Switch pin
Function
S4.1
On = Little endian
Off = Big endian
S4.2
Not used
S4.3
On = ARM Debug
Off = Boundary Scan
S4.4
Not used
S4.5 – S4.8
Not defined. Software configuration signals, which can be available for user
specific configuration.
