Fast Ethernet Switching System User’s Guide
Managing the DES-5024 35
Panel Conventions
Keystroke Conventions
Example Description
UP, DOWN, or TAB keys Select different items.
SPACEBAR Toggle-switch.
DEL, or BACKSPACE Remove any input character from the screen.
LEFT or RIGHT keys Move cursor backward or forward.
Ctrl-r Refresh Screen
Typographic Conventions
Example Description
:168.8.254.20 Each read only value follows a colon.
Each changeable value can be changed only by the toggle
switch.
[168.8.254.1] Each changeable value is enclosed in square brackets.
EXIT Uppercase letters indicate a COMMAND item.
Blinking Text Warning Message.
After you are finished viewing the help panel, press Enter to return to the main menu.
