Fast Ethernet Switching System User’s Guide
Installing the DES-5024
8
Installation Options
There are two options for installing the DES-5024: desktop/ shelf installation or rack
installation.
Follow these guidelines for desktop/ shelf installation or rack installation:
•
The surface must support 18 lbs or 8 kg.
•
The power source must be within six feet (1.82 m)
•
Power cord and cables should never be stretched
•
Leave at least two inches (5.08 cm) around the DES-5024 for ventilation
The following tools and materials may be necessary to install the DES-5024:
•
Screwdriver to install the brackets as needed
•
Wire cutters to cut cable as needed for network connections
•
Crimpers to crimp cable as needed
•
RJ-45 connectors as needed
•
SC fiber optic cable connectors
Refer to Chapter 3, Cable Specifications for cable types and specifications.
