To configure the UTM, you need an IP address and subnet mask that you will assign to the UTM,
as well as the IP address assigned to the host LAN interface. If the UTM and host are not on the
same subnet, you will also need the IP address of a gateway that can forward packets from the
UTM to the host.
Enter the following commands on the UTM console port.
login passwd=initial
rm
trk type=IPDSU
trk modtype=CPM
lo ipaddr=utm_ip_address submask=utm_subnet_mask
ga ipaddr=gateway_ip_address
trk dest=host_ip_address
Here the IP addresses and subnet mask are shown in bold Italics. You would replace these
names with numbers when you enter the commands.
Enter the following command to check the configuration:
