KP-10 External Keypad Revision 1
Operation MN/KP10.IOM
21
3.3 RSU C
OMMUNICATIONS
If the KP-10 is connected to a single RFT, the KP-10 global address of “*” is sufficient
for communicating with the terminal. There is no need to ascertain the actual address of
the RFT, in this case.
3.3.1 KP-10 K
EYPAD
V
ARIATIONS FOR AN
RSU
When the KP-10 is being used with an RSU, the valid function keys are as follows:
RFS RMS ASR
Scroll
ROS RESET
Figure 7. Function Keys for use with an RSU
Table 10. Descriptions of Function Keys used with an RSU
Function Key Description
[RESET] Reset External Keypad
[ROS] Redundancy Switch Operation Status
[RFS] Redundancy Switch Fault Status
[RMS] Redundancy Switch Maintenance Status
[ASR] Switch Address (See Note)
Note: The key labeled [KP ON] performs the
[ASR] function.
CAUTION
Make sure the [SHIFT] indicator LED is ON before using these keys.
