KP-10 External Keypad Revision 1
Operation MN/KP10.IOM
6
Table 2 KP-10 Configurations for Comtech EF Data Transceivers and Redundancy Units
Data Interface
Product RS232 RS485 RS422
RFT500, RFT505,
RFT700, RFT 1200,
RFT1225, RSU503,
RSU503L
KT/4856
Consisting of:
Cable: PL/4873
Terminal: PP/QTERMIV-
F079
KT/4856-1
Consisting of
Cable: PL/5103
Terminal:
PP/QTERMIV-F083
N/A
KST2000
KT/4856
Consisting of:
Cable: PL/4873
Terminal: PP/QTERMIV-
F079
KT/4856-1
Consisting of:
Cable: PL/5103
Terminal:
PP/QTERMIV-F083
KT/4856-2
Consisting of:
Cable: PL/6158
Terminal:
PP/QTERMIV-F123
KST2000A, B, or L
KT/8078
Consisting of:
Cable: PL/8077-1
Terminal: PP/QTERMIV-
F079
KT/8078-1
Consisting of
Cable: PL/8075-1
Terminal:
PP/QTERMIV-F083
KT/8078-2
Consisting of:
Cable: PL/8076-1
Terminal:
PP/QTERMIV-F123
RJU2000 N/A
KT/8078-1
Consisting of
Cable: PL/8075-1
Terminal:
PP/QTERMIV-F083
KT/8078-2
Consisting of:
Cable: PL/8076-1
Terminal:
PP/QTERMIV-F123
Tables 2, 3, and 4 show the pinouts on the KP-10 for the various data interfaces.
Table 3 KP-10 RS-232 Pinout
Pin Number Function I/O
2 RD/RX INPUT
3 TD/TX OUTPUT
5 GND
POWER RETURN
9 +V POWER
Table 4 KP-10 RS-485 Pinout
in Number Function I/O
1 -RX/TX DATA I/O
2 +RX/TX DATA I/O
5 GND POWER RETURN
9 +V POWER
