KP-10 External Keypad Revision 1
Operation MN/KP10.IOM
4
Table 1 describes the elements of the KP-10.
Table 1. KP-10 Elements Descriptions
Element Description
Display Screen The display screen is a monochrome, four-line
display screen featuring a user-controlled contrast
level.
Key Labels Blank, white key labels are located across the top
of the keypad, just under the display screen.
Indicator LEDs Indicator LED s above the function keys are used
to signal that the key is in use, or that there are
additional lines of a response message yet to be
displayed.
Keypad The keypad is a sealed-membrane type containing
alpha-numeric keys, cursor movement keys, and
specialized function keys.
Connector Port and Serial
Cable The KP-10 connects to RFTs and RSUs using
either an RS-232C or an RS-485 serial
communications port and cable. The serial
connection type is an option selected when the
KP-10 is ordered.
