KP-10 External Keypad Revision 1
Operation MN/KP10.IOM
14
2.4.3 C OMMUNICATION M ODE S ETTINGS
Setting Description
Baud
Rate Press [MODE] and the default Baud rate of 9600 appears. Change the Baud rate by pressing
[SCROLL UP] or [SCROLL DOWN] to raise or lower the Baud rate.
Data
Format Press [MODE] again, and the data format appears. Do not change the setting of “7e2”.
Serial
Mode Press [MODE] a third time, and the serial mode “BLOCK” will appear. Do not change the
setting of “BLOCK”.
Input
Ready Press [MODE] again, and the cursor moves to the upper left corner of the screen, indicating
the terminal is ready to receive input.
Note: See Figure 5 for mode and scroll key locations.
2.5 E
NTERING
C
OMMANDS AND
R
ECEIVING
R
ESPONSES
Enter a command on the KP-10 keypad, then send it to the terminal by pressing
[ENTER]. The command sent and the corresponding response returned from the terminal
are both visible on the display screen.
To type a command:
1 Press firmly on each character key in sequence.
2 Verify the characters on the display screen. The message format must be valid (see Chapters
3 and 4 for information on valid message formats for single and redundant systems,
respectively).
3 Press [ENTER] to send the completed command to the terminal.
On occasion, the response received from the accessed device is too large to fit on the
display. When this happens, the indicator LED above [FS] or [RFS] flashes. The entire
response can be viewed by scrolling through it. After scrolling through the message,
press [ENTER], [RESET], [OS], [MS], or [AS] to turn off the flashing LED.
To scroll through a response:
1 Press the function key under the flashing LED.
2 Read the displayed section of the response.
3 If the LED is still on, press the function key again to see more of the message.
