RSU-503 Redundancy Switch Unit Remote Control Operation
Rev. 8 B–7
B.3.3 Status Commands/Responses
Lock Mode Command
:
Response:
Status:
Response:
>add/LM_XX'cr''lf']
>add/LM_XX'cr''lf']
Where: XX = LK (lock) or EN (enable). Default = EN.
Lock mode prevents the current settings from being changed.
Uplink Switch
Config Command
:
Response:
Status:
Response:
>add/ULS_X'cr''lf']
>add/ULS_X'cr''lf']
Where: X = A or B.
This command is only applicable for the RSU-503L.
This command selects the uplink switch configuration, placing the
selected unit online, and the other on standby.
Uplink
Redundancy
Switch Mode Command
:
Response:
Status:
Response:
>add/ULM_YYYY'cr''lf']
>add/ULM_YYYY'cr''lf']
Where:
X = M (Manual) or A (Auto).
YYYY = MAN or AUTO.
This command places the switch uplink in either Manual or Auto
mode. In Auto mode, the switch will activate a switchover upon a
fault of the online unit.
Downlink
Switch Config Command
:
Response:
Status:
Response:
>add/DLS_X'cr''lf']
>add/DLS_X'cr''lf']
Where: X = A or B.
This command selects the downlink switch configuration, placing
the selected unit online, and the other on standby.
Downlink
Redundancy
Switch Mode Command
:
Response:
Status:
Response:
>add/DLM_YYYY'cr''lf']
>add/DLM_YYYY'cr''lf']
Where:
X = M (Manual) or A (Auto).
YYYY = MAN or AUTO.
This command places the switch downlink in either Manual or Auto
mode.
Hardware Command
:
Response:
Status:
Response:
>add/HWC_X'cr''lf']
>add/HWC_X'cr''lf']
Where: X = A (both Uplink and Downlink), B (Uplink only),
C (Downlink only), D (both Uplink and Downlink without LNA plate
- mask off DLA_FLT).
This command is used to configure the RSU for either "Uplink and
Downlink", "Uplink Only", or "Downlink Only" operation.
Switch
Initialization
Config Command
:
Response:
Status:
Response:
>add/SWI_X'cr''lf']
>add/SWI_X'cr''lf']
Where: X = A (UL/DL, last state on power-down) (default),
B (UL/DL A/A online), C (UL/DL B/B online), D (UL/DL A/B online),
E (UL/DL B/A online).
Note: Valid for all HWC configurations (see the HWC_ command).
This command is used to configure the switch online initialization
on power-up, and clears any ambiguity faults.
Redundancy
Operating
Status Command
:
Response: >add/ROS_'cr'
ULS_X'cr'
ULM_X'cr'
DLS_X'cr'
DLM_X'cr'
ASA_nnn'cr'
ASB_nnn'cr''lf']
Where:
X = A or B, uplink switches.
X = A (auto) or M (manual).
X = A or B, downlink switches.
X = A (auto) or M (manual).
nnn = 1 to 255, Unit A address.
nnn = 1 to 255, Unit B address.
This command returns a block of data from the switch, reflecting
the status of the current redundancy configuration.
