Installation RSU-503 Redundancy Switch Unit
2 Rev. 8
2.2 Inspecting the Equipment
1. Carefully check the equipment for damage incurred during shipment.
2. Carefully check the equipment against the packing list shipped with the
equipment to ensure that the shipment is complete. Refer to the following
paragraphs.
2.2.1 Included Parts
Note: Parts are not drawn to scale.
Qty. Description Qty. Description
1 RSU-503. 1 Installation and operation manual.
Note: The installation hardware listed below is included in the redundant system
installation parts kit KT/3577.
Qty. Description Qty. Description
1 Spar support bracket.
EFData Part # FP/3175.
Used for spar mount only.
4 5/16-18 x 1” bolt.
EFData Part # HW/5/16-18X1BLT.
2 Unistrut — 14” long.
EFData Part # FP/3595.
10 5/16” split lockwasher.
EFData Part # HW/5/16-SPLIT.
6 5/16-18 hex nut.
EFData Part # HW/5/16-18HEXNT.
10 5/16” flat washer.
EFData Part # HW/5/16-FLT.
