4.3 Terminal Interface
The Terminal Interface provides the user with a textual configuration dialog for
configuring the CMR-5930. This method of configuration should be used for initial
configuration of the unit; i.e., configuring the network parameters for the unit but not for
normal operation. The Web (HTTP) Interface is recommended for operational
management.
The Terminal Interface allows the entire unit to be configured and managed, but this
interface can only be used while a serial connection is present between the CMR-5930
and a PC. The same menu information is displayed via the Telnet interface as with the
serial interface – however, some specific features are available only via the the Terminal
Interface; these ‘serial interface only’ features are noted in this section. Detailed
information is provided about the menu features in Chapter 4.2 Web Interface.
Figure 4-13 shows the hierarchal structure of the Terminal Interface-based menus, and
the sections in this chapter which provide figures of these submenu pages.
Figure 4-13. Menu Hierarchy (via Terminal Interface)
Once the Terminal Interface is connected, as described in Chapter 2.4 Initial Configuration,
press the
key. The user should observe the the Main menu as shown in Figure 4-14.
Main Menu
(4.3.1)
Admin
(4.3.2)
Unicast Routing
Config (4.3.8)
ASI MPEG TS
Config (4.3.3.3)
ASI Service Filter
Config (4.3.3.2)
ASI MPE/IP Config
(4.3.3.1)
IGMP Config
(4.3.4)
Stats Menu
(4.3.6)
Network Config
(4.3.7)
See Figure 4-24
for hierarchy
ASI Config
(4.3.2)
Egress Config
(4.3.4)
