CMR-5930 Digicast Media Router PID Filter ASI Revision A
Introduction MN/PIDFILDC.IOM
Table 1-1. CMR-5930 Digicast PID Filter ASI Specifications
Parameter Specification
Dimensions 7.125” L x 8.125” W x 1.72” H (18.1L x 20.6W x 4.4H cm)
Weight < 6 lbs (2.7 kg)
Power 2.5 mm with screw type connector
RS-422 DB-9 (male)
ASI RX
ASI TX
BNC
Ethernet
(10/100BaseT)
RJ-45
Terminal
Redundancy
(Future)
RJ-12
Blue PWR
Green RED
Red ALARM
Green SYNC
Green E-SPD
Amber E-COL
Green E-RX
Green E-TX
Physical
LEDs
Green E-LINK
Power Input /
Consumption
100 to 200 VAC 47-63 Hz converted to +5VDC @ 2.5A
RS-422 Not active
ASI RX
ASI TX
EN50083-9
Ethernet
(10/100BaseT)
IEEE 802.3u
Console
Electrical
Redundancy
(Future)
RS-232
Temperature
Operating 32 ° to 104° Farenheit (0° to 40° Celsius)
Storage
(Non-operating)
-22 ° to 150° Farenheit (-30° to 65° Celsius)
Humidity
Operating 10 to 75% Non-condensing
Storage
(Non-operating)
Relative humidity to 95% with temperature ≤ 95 ° Farenheit (35° Celsius)
Altitude
Operating Up to 10,000 feet (3048 m) above sea level
Environmental
Storage
(Non-operating)
Survival up to 50,000 feet (15240 m) above sea level for up to 15 hours
1–4
