Comtech EF Data KST-2000L - Manual (Page 76)

Satellite Terminal System Revision 2
Equipment Outline Drawings MN/KST2000L.IOM
A.1 2 and 4 Watt SSPA Equipment Outline
8.72
#8-32 UNC-2A GND STUD
KPT 10 PIN MALE
"N" CONNECTOR
3.71
WR75 WAVE GUIDE
#6 HARDWARE THRU 1.04
1.12
2X .81
2X 2.89
3.00
%%c.38 THRU
(4X)
6.00
10.96
7.22
2.25
4.00
2.00
CL
Figure A-1. 2 Watt SSPA Equipment Outline
A–2
