Satellite Terminal System Revision 2
Summary of Specifications MN/KST2000L.IOM
2.1.2 Interface Requirements
2.1.2.1 M&C Interface
The M&C of the system shall be via the M&C connector located on the Converter Unit.
Specifications for the M&C interface are listed in Table 2-4.
Table 2-4. M&C Interface Specification
M&C Interface Specifications
Serial Data Signal Interface (User selectable)
EIA-232
EIA-485 (2-wire, half duplex)
EIA-485 (4-wire, half duplex)
Serial Data Baud Rates (User selectable) 300, 600, 1200, 2400, 4800, 9600, 19200 kbps
Discrete Alarm Outputs
Uplink Summary Alarm
Downlink Summary Alarm
System Summary Alarm
Form ‘C’ Relay Contacts
Form ‘C’ Relay Contacts
Form ‘C’ Relay Contacts
The converter unit and the SSPA are capable of being monitored and controlled via the
data connector whose connections are listed in Table 1-6 using Comtech EF Data
supplied software on an IBM compatible PC running DOS version
≤ 5.0 with at least
192K of available RAM and running with a 386SX processor or greater.
2–4
