Satellite Terminal System Revision 2
Connector Pinous MN/KST2000L.IOM
3–8
The 2 and 4 Watt SSPAs have a Type N, female (50 Ω) connector (J1) at one end for the
Ku-Band input and a WR-75 waveguide isolator (J2) at the other end for the Ku-Band
output.
3.2.1.10 LNB Connections
Note: The power supply for the LNB can be supplied by the KST-2000L.
The RF input of the LNB is a WR-75 waveguide flange. The RF OUT/REF/PWR IN
connector of the LNB is a type N, 50
Ω connector. It supplies the block-converted output
of 950 to 1700 MHz. It accepts +15 V at 400 mA, and a 10 MHz reference signal
supplied by the converter unit.
