2 converter spar arm mounting instructions – Comtech EF Data KST-2000L User Manual
Page 55
Satellite Terminal System
Revision 2
Equipment Mounting
MN/KST2000L.IOM
6.2.1.2 Converter
Spar
Arm Mounting Instructions
1. Position the Converter unit against the spar arm of the satellite dish and bolt the
two spar support brackets to the Converter unit brackets as shown in Figure 6-2
Utilize four each 1/4x-20x1” bolts, 1/4 split, and 1/4” flat washers.
Figure 6-2. Typical Converter Unit Installation on Spar
6–3
