Satellite Terminal System Revision 2
Connector Pinous MN/KST2000L.IOM
3.1.2 Description of Options
Table 3-1 lists the various equipment options, and Table 3-2 lists the available spare
parts.
Table 3-1. Description of Options
LNB OPTIONS (discrete narrow bands at 1.1db max NF only):
10.95 to 11.70 GHz Europe
11.70 to 12.20 GHz North American
12.25 to 12.75 GHz Aussat
MOUNTING HARDWARE OPTIONS:
Standard Prodelin spar offset antenna
Standard Channel Master spar offset antenna
Non-standard single thread converter pole-mount Kit
No mounting hardware beyond the “pick off points” on the completed assembly
For mounting requirements outside those previously indicated, please consult the factory for
availability.
CABLING OPTIONS:
No RF or control cabling. Includes only the prime power cable(s) and applicable MS
connectors
For cabling requirements outside those previously indicated, please consult the factory for
availability.
3.1.3 Spare Parts
Table 3-2. Spare Parts
Description P/N
2 Watt SSPA (white) PL/8308-1
4 Watt SSPA (white) PL/8235-1
M&C PCB assembly PL/8314-1
10.95 to 11.7 GHz Europe and also Intelsat
(11.2 to 11.7 GHz) KLNB (white) RF/LNB-KU-60-751
11.7 to 12.2 GHz North American KLNB
(white) RF/LNB-KU-60-752
12.25 to 12.75 GHz Aussat KLNB (white) RF/LNB-KU-60-753
10ft RF heliax “N” cable CA/3722-8
12ft RF heliax “N” cable CA/3722
15ft RF heliax “N” cable CA/3722-9
Base A/C converter power supply PS/AC150W02P01
Transmit reject filter (right angle) RF/TRF-KU-WR75R1
Transmit reject filter (straight) RF/TRF-KU-WR75G
3–2
