KEY
NO.
(V)CD36RNE
(V)CD36TNE
(V)CD36RPE
(V)CD36TPE DESCRIPTION
QTY.
1
116719-01
116719-01
Gas Valve Wire Harness (MV/PV)
1
2
116719-02
116719-02
Gas Valve Wire Harness (MV)
1
3
116719-03
116719-03
Gas Valve Wire Harness (PV)
1
4
116316-01
116316-01
Ignition Module Bracket
1
5
114886-01
114886-01
Door Retainer Bracket
1
6
111059-03
111059-03
Ground Wire Harness
1
7
110286-01
110286-01
Ignition Module Synetek
1
8
108863-01
108863-01
Plug 24” Supply Connect
1
9
108867-01
--
Pilot Orifice BL14LP (Propane/LP Gas)
1
--
108867-02
Pilot Orifice BL22N (Natural Gas)
1
10
108866-01
--
Pilot Assembly PSE (Natural Gas)
1
--
108866-02
Pilot Assembly PSE (Propane/LP Gas)
1
11
27206
--
Burner Orifice #44 (Natural Gas)
1
--
26482
Burner Orifice #55 (Propane/LP Gas)
1
12
26808
26808
Valve Bracket
1
13
24389
24389
Tube 3/8" Dia. x 11" Aluminum
1
14
24360
24360
Pilot Bracket
1
15
14569
--
Gas Control Valve Millivolt (Natural Gas)
1
--
14570
Gas Control Valve Millivolt (Propane/LP Gas)
1
16
14500
14500
Fitting 3/8" MPT x 1/2” Flare
1
17
14399
14399
Fitting Brass Elbow 3/8" MPT x 3/8" Comp. Tube
1
18
14396
14396
Fitting Brass Straight 3/8" MPT x 3/8” Comp. Tube
1
19
14299
14299
Air Shutter
1
20
14129
14129
Transformer, 24V Class 2
1
21
11404
11404
Cable, Tie 8.5” #10 Screwdown
1
22
11226
11226
Washer, Flat 7/8" ID x 2" OD x 1/8" Thick
2
23
11214
11214
Fitting Bulkead w/ Nut Brass
1
24
11201
11201
Nut, #8-32 Hex Zinc
4
25
11186
11186
Screw, #8-32 x 1” PPH
2
26
11187
11187
Screw, #8 x 1/4" PPH
1
27
11109
11109
Screw, #8-32 x 1/2” PPH
2
28
11107
11107
Screw, #10-32 x 1/4" PPH Zinc
4
29
11105
11105
Screw, #10 x 1/2" HWH LGM Zinc
11
30
11102
11102
Screw, #8 x 3/8" PPH F Zinc.
2
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 36 of this manual.
PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)CD36RNE, (V)CD36TNE, (V)CD36RPE, (V)CD36TPE
PARTS LIST
Models (V)CD36RNE, (V)CD36RPE, (V)CD36TNE, (V)CD36TPE
