27
www.desatech.com 116035-01B
OPERATING FIREPLACE
Electronic Ignition System
FOR YOUR SAFETY READ
BEFORE LIGHTING
WARNING: If you do not follow these instructions
exactly, a fire or explosion may result causing prop-
erty, damage, personal injury or loss of life.
A. This appliance is equipped with an ignition device which
automatically lights the pilot. Do not try to light the pilot
by hand.
B. BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floorbecause some gas
is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbor’s
Phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
C. Do not use this appliance if any part has been under
water. Immediately call a qualified service techni-
cian to inspect the appliance and to replace any part
of the control system and any gas control which has
been under water.
LIGHTING
INSTRUCTIONS
1. STOP! Read the safety information above.
2. Turn off all electrical power to the fireplace.
3. Turn wall switch to the OFF position.
4. Open lower louver panel.
5. Turn equipment shutoff valve clockwise to the OFF
position (see Figure ##). Do not force.
6. Wait five (5) minutes to clear out any gas. Then smell for.
gas, including near the floor. If you smell gas, STOP! Fol-
low “B” in the safety information above. If you don’t smell
gas go to the next step.
7. Turn equipment shutoff valve counterclockwise to.
the ON position. Do not force.
8. Close lower louver panel.
9. Turn on all electric power to the fireplace.
10. Turn the wall switch to the ON position.
11. Visually locate the pilot. The ignitor should begin to spark and
the main burner should ignite once flame appears at pilot.
• If lighting the appliance for the first time each season, it
may take several attemps before the supply gas can reach
the pilot and main burner.
• If the appliance will not stay lit after several attempts,
follow the instructions To Turn Off Gas To Appliance, be-
low, and call your service technician or gas supplier.
Equipment Shutoff Valve
OFF
ON
Adjustment
Screw
Figure 59 - Turning Equipment Shutoff Valve to the OFF Position
TO TURN OFF GAS
TO APPLIANCE
1. Turn off the wall switch.
2. Turn off all electric power to the appliance if service is to
be performed.
3. Open lower louver panel.
4. Turn equipment shutoff valve clockwise to OFF.
Do not force.
5. Close lower louver panel.
OPERATING FIREPLACE - Electronic Ignition System
For Your Safety Read Before Lighting
Lighting Instructions
To Turn Off Gas To Appliance
Pilot Burner
Ignitor
Sensor Rod
Figure 60 - Pilot
OPTIONAL WIRELESS
REMOTE OPERATION
Note: The WRC receiver and hand-held remote control kit
must be purchased separately (see Accessories, page 43). Follow
installation instructions included with the remote control.
1. Turn equipment shutoff valve to ON position. You can now
turn the burner on and off with the hand-held remote unit.
IMPORTANT: Be sure to press the ON/OFF buttons on the
hand-held remote control unit for up to 3 seconds to assure
proper operation.
2. Press the ON/OFF button to turn the burner on and off.
NOTICE: During initial operation of a new heater, the
burning of residues from the manufacturing process
of the firebox and logs will produce a paper-burning
smell and orange flames. Open a window for the first
few hours of operation to adequately vent this smell.
Optional Wireless Remote Operation
