PARTS LIST
Models (V)CD36RN, (V)CD36RP, (V)CD36TN, (V)CD36TP
KEY
NO.
(V)CD36RN
(V)CD36TN
(V)CD36RP
(V)CD36TP DESCRIPTION
QTY.
1
116317-01
116317-01
Remote Ignitor Bracket
1
2
114886-01
114886-01
Door Retainer Bracket
1
3
108085-01
--
Pilot Orifice #51(Natural Gas)
1
--
108085-02
Pilot Orifice #31 (Propane/LP Gas)
1
4
108084-02
--
Pilot Assembly (Natural Gas)
1
--
108084-03
Pilot Assembly (Propane/LP Gas)
1
5
27206
--
Burner Orifice #44 (Natural Gas)
1
--
26482
Burner Orifice #55 (Propane/LP Gas)
1
6
26808
26808
Valve Bracket
1
7
24389
24389
Tube 3/8" Dia. x 11" Aluminum
1
8
24360
24360
Pilot Bracket
1
9
14500
14500
Fitting 3/8" MPT x 1/2” Flare
1
10
14399
14399
Fitting Brass Elbow 3/8" MPT x 3/8" Comp. Tube
1
11
14396
14396
Fitting Brass Straight 3/8" MPT x 3/8” Comp. Tube
1
12
14389
--
Gas Control Valve Millivolt (Natural Gas)
1
--
14390
Gas Control Valve Millivolt (Propane/LP Gas)
1
13
14299
14299
Air Shutter
1
14
14261
14261
Ignitor Piezo
1
15
11226
11226
Washer, Flat 7/8" ID x 2" OD x 1/8" Thick
2
16
11214
11214
Fitting Bulkead w/ Nut Brass
1
17
11187
11187
Screw, #8 x 1/4" PPH
1
18
11107
11107
Screw, #10-32 x 1/4" PPH Zinc
4
19
11105
11105
Screw, #10 x 1/2" HWH LGM Zinc
10
20
11102
11102
Screw, #8 x 3/8" PPH F Zinc.
2
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 36 of this manual.
PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)CD36RN, (V)CD36TN, (V)CD36RP, (V)CD36TP
