28
www.desatech.com 116035-01B
OPERATING FIREPLACE
Continued
IMPORTANT: Do not leave the selector switch in the REMOTE
or ON position when the pilot is not lit. This will drain the
battery.
ON/OFF SERIES MODEL GHRCB
Figure 61 - Setting the Selector Switch, Gas Control Knob, and
Variable Control Knob for Remote Operation
O FF
PIL OT
O N
L
O IH
N
O
F F
O
E T
O
M E
R
ON
OFF
Blower Control Knob
(Optional Accessory) Variable
Control Knob
Selector Switch
in Remote
Position
Gas Control Knob
in ON Position
Hold the control button on the hand-held remote until burner
turns on. Hold the control button again until burner turns off
(see Figure 62).
TO LOCK
press both buttons on hand-held remote control until
light stops flashing, Hand-held remote control is now locked. If
the fire is on it will be turned off automaticalle. In the locked
state, the light will not light up when any button is pressed.
TO UNLOCK
press both buttons together on hand-held remote
control until the light stops flasing, The hand-held remote is
now unlocked.
Control Button
Turns Burners
On and Off
Figure 62 - On/Off Hand Held Remote Control Unit GHRCB
THERMOSTAT SERIES MODEL GHRCTB
The hand-held remote can be operated using either the manual
mode (MANU) or thermostat mode (AUTO) (see Figure 63).
To select Fahrenheit/Centigrade mode display, carefully press
the °C/°F mode button with the end of a paper clip or similar
blunt object.
Manual Mode
1. Press the POWER and LOCK buttons together to turn on
the hand-held remote control.
2. Press the MANU button to turn on the fireplace.
3. Press the POWER and LOCK buttons together to turn off
the fireplace.
Auto (Thermostat) Mode
1. Press the POWER and LOCK buttons together to turn on
the hand-held remote control.
2. Press the AUTO button to select this mode.
3. Setthe desired room temperature by pressing the TEMP
+ or - buttons.
4. Press the POWER and LOCK buttons together to turn off
the fireplace.
NOTE: Do not leave the hand-held remote in the AUTO mode
close to the fireplace. The radiant heat from the fireplace will
turn off the fireplace. Ideally, place the hand-held remote in the
center of the room facing towards the fireplace.
Digital Display
Shows
Temperature and
Settings
Turns Burners
On or Off
Decreases Room
Temperature in
AUTO Mode
Turns Hand-Held
Remote On or Off and
Allows You to Choose
the Manual Setting
Selects Auto Setting
Increases Room
Temperature in AUTO
Mode
Locks System to
Prevent Accidental
Ignition
Figure 63 - Thermostat Hand Held Remote Control Unit GHRCTB
NOTE: Do not hold the hand-held remote for a log time. Body
temperature will affect its operation in the AUTO mode.
Safety Features
When away from the home for an extended period of time or as a
child safety feature to prevent accidental ignition of the fire-
place, the receiver ON/OFF/REMOTE switch should be in the
OFF position.
Auto Shutoff Feature
1. If the average room temperature exceeds 82 degrees Fahr-
enheit (28 degrees Centigrade), the hand-held remote con-
trol will perform a safety override, and shut the fireplace
off. This feature is not available in the MANU mode.
2. The receiver continuously receives signals from the hand-
held remote to control the room temperature. If the hand-
held remote is misplaced, obstructed. or for any reason
cannot transmit to the receiver, the receiver will shut off
the fireplace after 8 minutes.
Key Pad Lock Feature
This feature allows the user to lock/unlock the keypad on the hand-
held remote in the MANU or AUTO mode to prevent inadvertent
operation (i.e. children operating the hand-held remote control,
etc.). The keypad is locked in either on or off, Press the POWER
and LOCK buttons together to turn the unit on or off.
OPERATING FIREPLACE
Optional Hand-Held Remote Operation (Cont.)
