Page 49
Mounting and cabling
Fig. 50: BG20000000, mounting the protection enclosure
3.5.3
ATEX Documentation
Note
Notes about operation of EtherCAT Box Modules (EPxxxxxxxx) in potentially
explosive areas (ATEX)
Pay also attention to the continuative documentationNotes about operation of EtherCAT
Box Modules (EPxxxxxxxx) in potentially explosive areas (ATEX) that is available in the
download area of the Beckhoff homepage http:\\www.beckhoff.com!
3.6
Signal connection
3.6.1
Digital inputs M8 and M12
The digital input modules acquire the binary control signals from the process level and transmit them to the
higherlevel automation unit.
The signals are optionally connected via screwin M8 connectors (EP1xxx0001) or screwin M12 connectors
(EP1xxx0002).
EP1xxx
49
Version 2.1.0
