Babycare TENS Elle TENS - Manual (Page 6)

ELLETENS+
B
o
o
s
t/
T
im
e
r
+
+
+ CH2 CH1
Mode
Opti
Max
BIRTH
PAIN
PELV
6
Low Battery Indicator
This sign will start flashing if the
batteries run low. If this is the
case, change both batteries.
Please refer to page 7 for
instructions.
Power Bar
This shows the output from 0 to 15
for both channel 1 and 2. Each
segment represents
approximately 7% of the total
output.
Contraction Timer
Starts by pressing the Boost
Button, this automatically records
the duration of your contractions.
Opti-Max
Indicates the Opti-Max output.
Refer to p14 for more details.
Pad contact warning
(safety cut-out)
This symbol will appear if any of
your pads are not attached
securely to the skin.
Mode 1 and 2
There are two mode ranges
available each with a Burst and
Boost function (see page 13).
BURST
This function is used at the
onset of labour and in between
contractions. There are two
Burst modes available indicated
by a 1 or 2. You can switch
between them by pressing the
Mode Button (see page 11).
BOOST
The Boost Button at the top right
of the unit activates the BOOST
mode. This function is used
during contractions. There are
two Boost modes available
indicated by a 1 or 2. You can
switch between them by
pressing the Mode Button.
Between Contraction Timer
Starts by pressing the Boost
Button, this automatically
measures the time interval
between your contractions.
Display symbols and their meanings in BIRTH mode
