25
ELLETENS+
B
o
o
s
t/
T
im
e
r
+
+
+ CH2 CH1
CH2 CH1
Mode
Opti
Max
BIRTH
PAIN
PELV On/Off Button
Opti-Max Key
Preset for use in the PELVIC mode.
Timer Button
Controls on your Elle TENS+
in PELVIC mode
The Elle TENS+ is very simple to use.
However, it is advisable to read these
instructions to obtain the most out of
the unit.
Please ensure that all of the
contraindications and
precautions have been read
thoroughly. See pages 34 and 35.
Leadwire Jack Plug Socket
(Use in channel 1 only)
Channel 1 Intensity
Adjustment Keys
N.B. Automatic Power Off
When the intensity levels are zero,
and the Elle TENS+ has not been in
use for 5 minutes, it will shut off
automatically.
Mode Button
Selects modes.
Space to attach neck cord
