Setting up your Elle TENS+ for PELVIC mode
Setting up in PELVIC mode
1. Remove the Vaginal Probe from its
packaging. Wash hands in soap and
warm running water. Liberally wash
the probe using the same method but
do not soak. Rinse all soap and residue
from hands and probe. Dry your hands
and the probe with a clean cloth/paper
towel and allow to air dry.
2. Take one of the leadwires and insert
the black jack plug into the channel 1
(only) socket at the top of
the Elle TENS+ unit
(the socket to the right when
viewed from the back).
3. Now insert the pins (at the other
end of the leadwire) into the
sockets attached to the Vaginal
Probe.
4. Apply a thin coating of
lubricating gel to the probe.
5. Insert the probe until the flange
at the base of the probe is sited
between the labia as shown in the
diagram. There is no need for
precise orientation. 28
Channel 1
only
Jack Plug
Pins Sockets
