Low Battery Indicator
This sign will start flashing when
the batteries are running low.
If this is the case, change both
batteries. Please refer to page 5
for instructions.
Power Bar
This shows the output from 0 to 15
for channel 1. Each segment
represents approximately 7% of
the total output.
Opti-Max
Preset for use in the PELVIC mode.
Mode Indicator
indicates mode currently in use.
For more information on the
modes available see opposite
page.
Probe contact warning
(safety cut-out)
This symbol will appear if the
probe is not inserted correctly or
insufficient gel has been used.
Timer
Shows your length of treatment which
is preset in the PELVIC mode.
Display symbols and their meanings in PELVIC mode
