Babycare TENS Elle TENS - Manual (Page 32)

Specifications
Unit Size 115mm x 55mm x 30mm
Unit Weight 75 grams
Output Jacks CE Touch-proof jacks
Display
Digital LCD - 8 seven segment digits and around
95 segments
Automatic Power Off Will switch off after 5 minutes if not used
Battery Low Detect 2.2v ± 0.2v
Battery 2 x 1.5v AA Battery (Type LR6)
Operating Environment
Temperature 0-40˚C
Air humidity 30-75%
Air pressure 700 hPa-1060 hPa
Storage and Transport
Environment
Temperature 0-40˚C
Air humidity 30-90%
Air pressure 700 hPa-1060 hPa
General
Programme Display Output Frequency / Duration
Burst Burst 1
Pulse Frequency (16Hz) Pulse Width (150 Ȑs)
1 burst per second, 8 pulses per burst*
Burst Burst 2
Pulse Frequency (32Hz) Pulse Width (150
Ȑs)
2 bursts per second, 8 pulses per burst*
Boost Boost 1
Pulse Frequency (80Hz) Pulse Width (150 Ȑs)
continuous*
Boost 2 Boost 2
Pulse Frequency (100Hz) Pulse Width (150 Ȑs)
continuous*
Output Channel Dual Channel
Output Waveform Symmetrical bi-phasic rectangular
Output Voltage 0 - 55v zero to peak adjustable in 15 steps at 500q load
Output Intensity
0 - 110mA adjustable in 15 steps at 500q load Intensity
level will drop back to zero after programme changes
BIRTH mode
Equipment type
Dual Channel Digital TENS
Classification
This unit is fully compliant with EEC Directive 93/42/EEC,
classified as internally powered equipment type BF.
It is intended for continuous operation.
* Default pulse width after mode changed (pulse width not changed when switched between
BURST and BOOST mode) 5 selectable pulse widths in all modes: 50, 100, 150, 200, 250
32
* Pulse width adjustment does not change when switching between Burst and Boost modes.
Default pulse width is 150 Ȑs. There are 5 adjustable pulse widths selectable in all modes: 50, 100,
150, 200 and 250 Ȑs.
