5
ELLETENS+
B
o
o
s
t/
T
im
e
r
+
+
+ CH2 CH1
CH2 CH1
Mode
Opti
Max
BIRTH
PAIN
PELV
Controls on your Elle TENS+
in BIRTH mode
The Elle TENS+ is very simple to use.
However, it is essential to read these
instructions to obtain the most out of
the unit.
Please ensure that all of the
contraindications and precautions
have been read thoroughly.
See pages 34 and 35.
On/Off Button
N.B. Automatic Power Off
When the intensity levels are zero,
and the Elle TENS+ has not been in
use for 5 minutes, it will shut off
automatically.
Channel 2 Intensity
Adjustment Keys Channel 1 Intensity
Adjustment Keys
Opti-Max Key
Adjusts depth of the pulses:
Refer to p14 for more details.
Mode Button
Selects modes.
Space to attach neck cord
Boost/Timer Button
Used for an extra surge of
power during contractions
and also activates
Contraction Timer.
Leadwire Jack Plug Sockets
