17
ELLETENS+
B
o
o
s
t/
T
im
e
r
+
+
+ CH2 CH1
CH2 CH1
Mode
Opti
Max
BIRTH
PAIN
PELV On/Off Button
Opti-Max Key
Adjusts depth of the pulses
Refer to p22 for more details.
Mode Button
Selects one of four different modes:
Refer to p19 for more details.
Timer Button
Controls on your Elle TENS+
in PAIN mode
The Elle TENS+ is very simple to use.
However, it is advisable to read these
instructions to obtain the most out of
the unit.
Please ensure that all of the
contraindications and
precautions have been read
thoroughly. See pages 34 and 35.
Channel 2 Intensity
Adjustment Keys
Channel 1 Intensity
Adjustment Keys
N.B. Automatic Power Off
When the intensity levels are zero,
and the Elle TENS+ has not been in
use for 5 minutes, it will shut off
automatically.
Space to attach neck cord
Leadwire Jack Plug Sockets
