581396-1.2.doc SNAP 500 Short Feed Addendum
Short Feed Nip Parts List
1 WASHER, .125 X .313 X .031 990448 19
1 BRACKET, STATIC BRUSH 587116 18
1 BRACKET, STRIPPER PLATE 587115 17
1 ELECTRICAL, STATIC BRUSH 584034 16
1 4-40 X 1/4 THUMB SCREW 991471 15
1 10-32 X 3/4 PPH SCREW 991377 14
1 10-32 X 1/2 PPH SCREW 991376 13
1 4-40 X 1/4 PHIL PAN HEAD SCR 989983 12
2 COMPRESSION SPRING 991523 11
4 6-32 X 1/2" SHCS 990017 10
2 6-32 X 1/4 BHCS 990019 9
4 "O" RING, 1/16 X 7/32 X 11/32 991614 8
1 SHAFT, REAR UPPER ROLLER 587084 7
1 SHAFT, FRONT UPPER ROLLER 587086 6
1 SHAFT, REAR LOWER ROLLER 587095 5
1 SHAFT, FRONT LOWER ROLLER 587096 4
1 BKT, OUTER ROLLER SUPPORT 587097 3
1 PLATE, OFFSET 587099 2
1 BKT, INNER ROLLER SUPPORT 587098 1
QTY DESCRIPTION PART NO. ITEM
