Avery Dennison SNAP 500 Short Feed User Manual
Page 18
581396-1.2.doc
SNAP 500 Short Feed Addendum
9. Re-attach the nip roller assembly to the machine using the (2) 10-32 round head, mount screws from step 1. Re-
attach the 20T drive gear (inside back cover – from step 1 on page 17). Re-attach the stacker. Plug the stacker in
and turn the machine on.
SHORT FEED
NIP ROLLER
NIP ROLLER ASS'Y
MOUNT SCREWS
STACKER
