Avery Dennison SNAP 500 Short Feed User Manual
Page 12
581396-1.2.doc
SNAP 500 Short Feed Addendum
3. Test that feed knob turns freely by hand. Check that all steps have been done correctly. Check that all nip rollers turn
freely when feed knob is rotated. If a bind detected, adjust gear train mounting screws (shown in previous step).
FEED KNOB
NEW NIP ASSEMBLY
NIP ROLLERS
