INSTALLATION
RACK MOUNTING:
If needed, fit the rack mounting brackets to each side of the ECS by using the 6 pcs Phillips M3X
screws supplied with the package.
SITTING
The ECS takes only a single 19’’ rack space and generates little heat itself. Consider leaving
enough ventilation space above and below the unit. Do not mount the ECS directly above heat
generating devices like power supplies or power amplifiers.
ECS cooling is provided by a fan at the left side of the unit. Be sure to not to block the air vent
holes along the sides of the housing. Normal operation is ensured within a temperature range
between 0°C and 40°C (32 °F to 104 °F).
POWER CONNECTION:
Connect the AC to the mains supply via a power cord. Check your line voltage before plugging in.
The power supply of the ECS accepts AC voltages ranging from 100 V to 240 V, 50/60 Hz. The ECS can
also be powered up from a 24 VDC supply; i. e. backup battery.
