112
Display
LED
indicator
x 3,
Button x 3
LED indicator x 3, Button x 3,
Back-lit LCD Display 16 x 2-line
Multilingual
Communic
ation
interfaces
Centronics
parallel,
RS-232
serial
(baud rate
to 115200
bps),
USB
Centronics parallel,
RS-232 serial,
USB,
PS/2 interface,
Ethernet 10/100MB (X-2300E / X-2300ZE /
X-3200E / X-3200ZE)
Media
Types Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal
paper or plain paper, fabric labels
Maximum
Label
Roll
Diameter
Max. media width: 4.4” (112mm)
Min. media width: 1” (25.4 mm)
Media thickness:
0.0025”~0.01”(0.0635mm~0.254mm)
8
”(203mm) OD on a 3”(76mm) ID core
7”(177.8mm) OD on a 1.5”(38mm) ID core
Min Length: 0.79
“(20mm) for rotary cutter option
Ribbon
Wax, Wax/Resin, Resin
(ribbon wound ink-side out or ink-side in available)
Ribbon
Size
Ribbon width: 1”~4”
(25.4 mm~101.6 mm)
Ribbon Length: max 360m Wax, 300m Semi-Resin
Ribbon roll max OD 3
” (76 mm)
Core size ID 1”(25.4 mm)
