Identifying external components, Dentifying, Xternal – D-Link DI-1162M User Manual
Page 11: Omponents
DI-1162/DI-1162M Remote Access Router
5
♦
Rack mount kit including six screws and two mounting brackets.
♦
One CD-ROM disc or floppy diskette containing the Windows-based Router Configuration Utility.
♦
This User’s Guide.
If any item is found missing or damaged, please contact your local D-Link Reseller for replacement.
Identifying External Components
The following section illustrates the different components on the router’s front and rear panels. Before using the
router it is highly recommended to familiarize yourself with these components to ensure effective use of the
device.
♦
LED Indicators The front panel consists of the LED indicators of the router. The LED indicators are used to
facilitate monitoring and troubleshooting. Please refer to the following chart for detailed descriptions of these
indicators.
