Page 128
Page 122 -
Pointmaker CPN-5000 Color Video Marker
Boeckeler Instruments, Inc.
Overview
Section Six:Using RS-232 Commands
(IFI) Set Image File Index
The “IFI” command sets the image file index, designating where the numbering of
saved images will start.
Set the image file index. nnnnn is a five digit number. The
combination of image file prefix and index must be equal to or
less than 8 characters.
(IFP) Set Image File Prefix
The “IFP” command sets the image file prefix to be used for saved images.
Set the image file prefix. ccc... is less than or equal to 3 characters,
terminated with a carriage return.
The combination of image file prefix and index must be equal to or less
than 8 characters.
(IM) Identify Mode for Multiple Users
The “IM” command designates the mode to use when multiple digitizing tab lets
or touch screens are installed. When PRIORITY USER mode is selected, you will
also need to send the command designating which controller (COMM #) is the
priority user.
Assigns Open Mode.
Assigns Selective Mode.
Assigns Priority User Mode.
Sets COMM port for Priority User.
XX = the COMM port (01-10) The port selected should be con nected to a
digitizing tablet or touch screen.
