Gps module connector mcu gpio connector, Gps module connector, Mcu gpio connector – NEXCOM VTC 1010 User Manual
Page 44
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
30
Chapter 3: Jumpers and Switches
VTC 1010 User Manual
GPS Module Connector
Connector size: 1 x 6 = 6-pin header
Connector location: J14
Pin
Definition
Pin
Definition
1
GPS_BAT
2
GPS_LED
3
GPS_CTX
4
GPS_CRX
5
GND
6
VCC3_GPS
1
6
MCU GPIO Connector
Connector size: 1 x 6 = 6-pin header
Connector location: J12
Pin
Definition
Pin
Definition
1
GND
2
MCU GPO2
3
MCU GPO1
4
MCU GPI2
5
MCU GPI1
6
GND
1
6
