Dugan Model M User Guide
Dugan Control Panel Software
31
Bypass
When bypass is active, the signal passes through without automixing. A bypassed
channel appears inactive, with all lights extinguished.
Figure 5-4
bypass
button lit
Man
and bypass modes are similar:
•
bypass
makes an instantaneous transition, which can cause an audible click.
•
man
performs a quick fade without sonic artifacts.
To deactivate bypass, you can:
•
Click bypass again;
- OR -
•
Click any of the three channel mode buttons.
Channel Modes
There are three channel modes: man, auto, and mute. Changing modes initiates a
half-second fade to the new mode. Like radio buttons, you can only choose one
mode at a time.
Figure 5-5 Channel modes
