Item Description
1. Hard disk bay A comparrtment that houses the hard disk
2. Stylus pen holder Where the stylus pen is lodged.
3. Ventilation openings Openings where cool air enters the computer.
BOTTOM VIEW
Item Description
1. CMOS battery A comparrtment that houses the CMOS battery and the
module compartment and of DRAM memory.
module of DRAM memory.
2. Reset switch A switch for resetting the computer.
3. Battery latches (x2) Latches that impede the battery pack from moving
out of place.
4. Ventilation openings Openings where cool air enters the computer.
25
