Dimension One Spas - Aquatic Fitness System - Owner’s Manual

Light Button

The LIGHT button controls the lighting of your spa. See the Light
control section (pg. 9).

Up (+) and Down (-) Buttons

You can control the water temperature by using the Up (+) and
Down (-) Buttons. The SET TEMPERATURE Icon appears in
the lower right side of the Window to indicate that the temperature
shown is a “target setting” and not the actual temperature. The
Temperature Icon will appear at the top of the window if your new
setting requires more heat.

Once the new temperature is set, the Display Window once again
shows the actual spa water temperature. The spa will heat to the
new temperature automatically.

Program Button

Push the PROGRAM Button to begin the process of
programming, or reprogramming, the spa. See Programming the
Spa Functions for details (pg. 15).

Heat Status Light

The Heat Status Light is illuminated whenever the heater is on.
Additionally, a heat icon will also be displayed in the upper left
corner of the Digital Display Window.

Dimension One Spas ICON
(Logo)

Push the Dimension One ICON button to see the time of day. If no
other button is pushed within 5 seconds, the display reverts to the
water temperature.

Battery Backup - The Dimension One Spas scrolling message center control panel
has a battery back-up that will retain the time of day for 30 days without an active
power source. The control panel also stores your custom programming commands
for up to 40 years without power. This battery backup will not provide power to heat
or operate the hot tub.
