43

© 2 0 0 6 D i r e c t e d E l e c t r o n i c s

Since most newer vehicles come equipped with a factory alarm

system, it is sometimes necessary for the factory alarm to be

armed/disarmed when unlocking the doors and disarmed while

remote starting the vehicle.

Locate the factory alarm arm/disarm wires using the web site

vehicle information. Once the suspect wires are located, place

the multi-meter’s red lead to a (+)12 volt constant source and

secure it. Put the multi-meter in the DC position then probe the

suspect wire with the black lead of your meter. While probing

the wire, place the key in the drivers door cylinder. Turn it to the

unlock position and hold it when testing for the disarm wire.

The LED tester should illuminate Green and will extinguish

when the key is released.

When the correct wire has been found, solder the LIGHT

Green/Black (H1/7) wire of the main harness to the wire which

activates in the unlock position when the key is turned. After this

wire has been connected wrap the connection with electrical

tape.

note: On some vehicles the Factory Alarm Disarm wire is
connected to a Body Control Module or a Door Module.
If you find this configuration, please call Directed
Technical Support at 1

1--8

80

00

0--4

47

77

7--1

13

38

82

2.

note: Some vehicles use a + trigger system. Use the
www.designtech-intl.com website to determine if your
vehicle has a + trigger system. If this vehicle has this sys-
tem call 1

1--8

80

00

0--4

47

77

7--1

13

38

82

2 for live technical assistance as

special wiring and an additional relay is required.
