5–2 Chapter 5: Power Measurement
Power Design Example
Stratix III Development Kit User Guide © August 2008 Altera Corporation
The LEDs in Table 5–2 indicate the power-state values of the design example as
User_PB1 advances frequency.
The LEDs in Table 5–3 indicate the power-state values of the design example (and
number of output pins, when enabled by User_PB3) as User_PB2 advances resource
utilization.
The resource state ( Table 5–3 ) controls the number of I/O pins used. Each resource
increment adds eight additional I/O pins ( Table 5–3 ). Similarly, the overall design
frequency ( Table 5–2 ) sets the toggle frequency of these I/O pins.
Table 5–2. Power State Indicators for Frequency
LED1 (C23) LED0 (F21) Frequency (MHz)
0 0 0
0 1 33
1 0 67
1 1 100
Table 5–3. Power State Indicators for Resources
LED6
(F19) LED5
(C19)
LED4
(D19)
LED3
(A23)
LED2
(B23)
Resources
(%)
Number of
Outputs
0 0 0 0 0 5 8
0 0 0 0 1 10 16
0 0 0 1 0 15 24
0 0 0 1 1 20 32
0 0 1 0 0 25 40
0 0 1 0 1 30 48
0 0 1 1 0 35 56
0 0 1 1 1 40 64
0 1 0 0 0 45 72
0 1 0 0 1 50 80
0 1 0 1 0 55 88
0 1 0 1 1 60 96
0 1 1 0 0 65 104
0 1 1 0 1 70 112
0 1 1 1 0 75 120
0 1 1 1 1 80 128
1 0 0 0 0 85 136
1 0 0 0 1 90 144
1 0 0 1 0 95 152
1 0 0 1 1 100 160
