2011-2012 6.4L Manual Challenger
Tuner Kit (cont’d)
Part No. 4CL218-174L
PaRTS LIST
®
IMPORTaNT: Before beginning installation, verify that all parts are included in the kit. Report any
shortages or damaged parts immediately.
ENGINEERING, INC.
PaRT NO. DESCRIPTION QTY PaRT NO. DESCRIPTION QTY
008110 SMaLL SILVER DIE CUT DECaL 2
008130 LICENSE PLaTE FRaME, VORTECH 1
008341 VORTECH CHaRGE COOLER DECaL 1
008447 1 YR S/C STRT INFO PKG aSY VOR 1
009035 S/C LUbE, bOTTLED, VORT 3-PaCK 1
2a046-106 bELT PREMIUM 104.5”, GaTES 1
2F329-134 V3 S/C aSY, 2011 6.4L HEMI CHa 1
4CL020-020 INSTR MaN, ‘11 6.4L HEMI CHaL. 1
4CL010-160 bRKT, FLDYNE CHaLLENGER DRVR 1
4CL010-170 bRKT, FLDYNE CHaLLENGER PaSS 1
4CL110-064* S/C MTG bRKT aSY,11-12 HEMI M6 1
4CL110-070* PWR STEERING aSSY, 6.4L HEMI 1
4CL110-110
aSSY, DaMPER PIN, HEMI 1
4GR010-110 GUIDE, DWL PIN INST 1
7C014-095 M14-1.5 X 95MM SHCS 1
7U250-019 DOWEL PIN, 1/4X1/2 +.001” 1
7U250-026 DRILL BUSHING, 1/4 ID, 3/8 OD, 1/2L 1
4CL112-030 aIR INLET aSSY, HEMI 1
4CL010-180 BRKT, CHALLENGER AIR INLET 1
4CL012-030 DUCT, INLET 08 HEMI CHALLENGER 1
7A250-039 1/4-20 X 3/8” SHCS ZINC PLTD 2
7J250-001 1/4 WASHER, SAE, PLTD 2
7R002-056 #56 SAE TYPE F SS HOSE CLAMP 1
7R002-080 #80 SAE TYPE F SS HOSE CLAMP 1
7S500-351 INLET SLEEVE, HEMI, 5 X 3.5 1
8H040-235 AIR FILTER, 4” FLG X 7.0L 1
7P500-009 1/2”X90 HOSE BARB UNION 1
7U030-036 1/2” OIL DRAIN HOSE 4’
8H040-300 AIR FILTER 300C 1
7U032-020 3/8 P/S HOSE 32”
4CL112-084 aIR DISCH aSSY, 11-12 6.4L HEMI 1
4CL010-270 BRKT, DUCT SUPRT, P. SIDE, 6.4 1
4CL010-300 BRKT, DUCT SUPRT, REAR, 6.4 1
4CL012-074 DISCHARGE DUCT “A” COATED 1
4CL012-084 DISCHARGE DUCT “B” COATED 1
4CL012-094 DISCH TUBE “C”, 2011-12 6.4L H 1
7P750-502 REDUCER, 3/4” TO 1/2” COUPLER 1
7PS275-100 SLEEVE, BLACK, 2.750D X 1.0 1
7PS275-300 SLEEVE, BLACK, 2.75ID X 3.0 3
7PS350-277 ELBOW, SIL, 3.5X2.75 90º, BLK 1
7P375-156 3/8 X 3/8 X 5/32 MALE BARB TEE 1
7R002-016 #16 SAE TYPE F SS HOSE CLAMP 2
7R002-044 #44 SAE TYPE F SS HOSE CLAMP 9
7R002-056 #56 SAE TYPE F SS HOSE CLAMP 1
7U030-046 5/32” VACUUM LINE 5’
7U034-016 1” GS HEATER HOSE .25’
8D001-004 COMPRESS BYPASS VALVE, G2 1
8H040-075 FILTER, 1” BYPASS VALVE 1
5W001-093 HaRNESS EXTENSION, ETC, 2011 1
8N006-020 WaTER COOLR, FLDYN DUaL PaSS 1
8N105-220 WaTER TaNK aSSY, 2011 6.4 HEMI 1
4CL010-190 BRKT, CAC TANK, HEMI 1
7A250-050 1/4-20 X .50 SHCS GR8 ZINC PLT 4
7A250-051 1/4-20 X .50 HHCS GR5 ZINC PLT 2
7A250-101 1/4-20 X 1 HHCS ZINC PLTD 1
7E010-075 #12 X 3/4” SHT METL SCRW HEX 8
7J250-001 1/4 WASHER, SAE, PLTD 7
7P375-075 3/4” HOSE BARB UNION, BRASS 5
7P500-026 1/2NPT X 3/4 BARB 90º BRASS 2
7P500-075 1/2NPT X 3/4 HOSE FIT STRT NIC 5
7R007-001 NYLON RATCHET CLAMP 1-1/8” 19
7U038-000 3/4” HEATER HOSE 9’
7U038-012 HOSE, 3/4 DIA 90º, 4 X 12 LEGS 5
7U038-150 HOSE, 3/4 D X 150º MOLDED HOSE 1
7U100-044 TIE WRAP, 4” NYLON 10
7U100-055 TIE WRAP, 7.5” NYLON 10
8N055-030 TANK, WATER TRIANGLE SHAPE 1
8N055-050 PLASTIC CAP, SURGE TANK 1
7P500-034 1/2NPT X 3/4 BARB 90º, NICKEL 2
7P500-035 FITTING, 1/2 NPT X 3/4 BARB X 2
4CL010-290 BRKT, SURGE TANK, FILL ’11 6.4 1
8N056-060 SURGE TANK, PLASTIC 1
7F375-016 3/8-16 HX NUT 1
2A017-881-01 SPACER, .875 OD X .532 LONG 1
7J375-044 3/8 SAE WASHER, PLTD 2
7A375-350 3/8-16 X 3.5” HX HD GR5 1
4CL010-280 MTG BRKT, CAC, 2011 6.4 HEMI 1
4CL010-160 BRKT, FLDYNE CHALLENGER DR 1
4CL010-170 BRKT, FLDYNE CHALLENGER PA 1
8N107-190 WaTER PUMP MTG aSSY, 07 CHGR 1
5W001-011 16-14 GA RING TERM .26” HOLE 1
5W001-013 14-16 GA BUTT CONN BLU INSUL 2
5W001-024 MINI ATC FUSE TAP 1
5W001-025 FEMALE SLIDE,INSULATED,MINI 1
5W001-054 18 GA FUSE HOLDER 1
5W014-030 14GA STRD WIRE BLACK 5
7R003-027 ADEL CLAMP,1-11/16” 1
8F001-402 PUMP, WATER, PIERBURG 1
8N100-001 NYLON MOUNTING KIT 1
8N201-394 WELDED,CORE aSSEMbLY,HEMI 1
*SEE PAGE VIII FOR INDIVIDUAL COMPONENTS IN ASSEMBLY
