Vortech 2011-2012 6.4L Hemi Challenger - Manual (Page 8)

P/N: 4CL020-020 v1.0, 12/02/2014
©2014 Vortech Engineering, Inc.
All Rights Reserved, Intl. Copr. Secured
viii
2011-2012 6.4L Manual Challenger
Tuner Kit
Part No. 4CL218-174L
PaRTS LIST
®
IMPORTaNT: Before beginning installation, verify that all parts are included in the kit. Report any
shortages or damaged parts immediately.
ENGINEERING, INC.
PaRT NO. DESCRIPTION QTY PaRT NO. DESCRIPTION QTY
008110 SMaLL SILVER DIE CUT DECaL 2
008130 LICENSE PLaTE FRaME, VORTECH 1
008341 VORTECH CHaRGE COOLER DECaL 1
008447 1 YR S/C STRT INFO PKG aSY VOR 1
009035 S/C LUbE, bOTTLED, VORT 3-PaCK 1
2a046-106 bELT PREMIUM 104.5”, GaTES 1
2F329-134 V3 S/C aSY, 2011 6.4L HEMI CHa 1
4CL020-020 INSTR MaN, ‘11 6.4L HEMI CHaL. 1
4CL010-160 bRKT, FLDYNE CHaLLENGER DRVR 1
4CL010-170 bRKT, FLDYNE CHaLLENGER PaSS 1
4CL110-064 S/C MTG bRKT aSY,11-12 HEMI M6 1
008725 CAP, TAMPER PROOF, VORT S/C 2
2A017-016 PILOT, 6203/5 BRG, 3/8 SCREW 1
2A017-093 SPACER, S/C PULLEY, .093” 1
2A017-105-222B SPCR, BLK 1”OD X .328”ID X 2.225 7
2A017-462 SPACER,IDLER SMOOTH 6RIB 1
2A017-156 SPCR, SM IDLER, DBL BRG JACK 1
2A017-876-12 SPACER, .875 OD X .475 LONG 2
2A036-136 S/C PULLEY 3.60” 6 GROOVE W/FL 1
2A040-051 PLY RETAINER, TAMPER PRF CAP 2
2A040-061 RETAINER CUP, VORT S/C PLY 2
2A017-251 SPACER, .63”OD X .326ID X .25 2
2A042-080 BELT, GATES 20MM, 80 TOOTH 1
2D070-159 LARGE BEARING,EXTENDED DRIVE 2
2D070-171 JACKSHAFT, C5, H900, 1INCH 1
4CL010-230 PLT, SUP, REAR, 09 5.7L M6 HEM 1
4CL010-221B PLATE, CYL HEAD 09-10 5.7L HEM 1
4CL010-044B SC, MTG, PLT, BLACK ANODIZE 1
4CL016-011 HUB, PWR STR PLLY, HEMI CAR 1
4CL017-011 SPACER, IDLER, 2011 6.4 HEMI 1
4CL016-021 PULLEY, PWR STR, HEMI CAR 1
4CL116-350 IDLER ASSY, 20MM GILMER, SRT8 1
4FD017-011 PILOT, 6203/5 BRG, 1/2 SCREW 1
4FT017-080 SPCR, COOLER SUPPORT 1
4GR032-032 PULLEY,JACKSHAFT,C5,20MM,32T 1
4GR116-300 IDLER ASSY, 20MM GILMER, C5 1
4HS017-041 SPACER, LOWER S/C PLT S2000 2
4NZ030-041 BEARING HSG, 350Z 1
7A250-075 1/4-20 X .75 SHCS PLTD 6
7A312-152 5/16-18 X 1.5 SHCS, ZN PLT 4
7A375-124 3/8-16 X 1-1/4 HHCS, G5, PLATE 4
7A375-225 3/8-16 X 2-1/4 HXHD G8 1
7B375-075 3/8-24 X 3/4” GR8 HXHD BOLT 1
7B375-150 3/8-24 X 1-1/2 GR8 HX 1
7C012-100 12MM X 100MM X 1.75 HXHD BOLT 1
7C080-066 M8 X 1.25 X 65 HXHD CL10.9 1
7C080-090 M8 X 1.25 X 90 HXHD CL10.9 7
7C080-100 M8 X 1.25 X 100 HXHD ZN PLT 3
7C080-120 BOLT, 8MM X 120MM X 1.25 HXHD 1
7G010-175 12MM X 1.75 NUT 1
7J012-092 12MM WASHER, FLAT 1
7J312-000 5/16 FLAT WASHER-SAE 11
7J375-044 3/8 SAE WASHER, PLTD 4
7J500-002 1/2” WASHER, SPLIT LOCK 1
7K250-001 1/4” AN WASHER 6
7U100-069 KEY, 3/16 SQUARE X .73 LONG 1
7U100-073 KEY, 3/16 SQUARE X 1.375 LONG 1
7U100-084 SNAP RING, EXT DRV HOUSING 1
7X100-027 WAVE WASHER, LARGE, V2 INPUT 1
4CL110-070 PWR STEERING aSSY, 6.4L HEMI 1
2A017-251 SPACER, .63” OD X .326” ID X .25 2
4CL010-261 MTG BLOCK, P/S, 2011 6.4 HEMI 1
7P375-075 3/4” HOSE BARB UNION, BRASS 1
7P500-036 ELBOW, 1/2 NPT, STRT, 45 DEG 1
7P500-078 1/2 NPT X 3/4 HOSE FIT STRT 1
7R002-010 #10 SAW TYPE F SS HOSE CLAMP 2
7R004-007 STEPLESS CLAMP, 28.6 X 7MM WIDE 2
7U038-030 HOSE, P/S, 3/4 ID 1.5
4CL110-110* aSSY, DaMPER PIN, HEMI 1
4CL112-030* aIR INLET aSSY, HEMI 1
4CL112-084* aIR DISCH aSSY,HEMI CaR, G2 1
5W001-093 HaRNESS EXTENSION, ETC, 2011 1
8N006-020 WaTER COOLR, FLDYN DUaL PaSS 1
8N105-220* WaTER TaNK aSSY, 2011 6.4 HEMI 1
8N107-190* WaTER PUMP MTG aSSY, 07 CHGR 1
8N201-394 WELDED,CORE aSSEMbLY,HEMI 1
*SEE PAGE IX FOR INDIVIDUAL COMPONENTS IN ASSEMBLY
