2011-2012 6.4L automatic Challenger
Tuner Kit (cont’d)
Part No. 4CL218-164L
PaRTS LIST ®
IMPORTaNT: Before beginning installation, verify that all parts are included in the kit. Report any
shortages or damaged parts immediately.
ENGINEERING, INC.
PaRT NO. DESCRIPTION QTY PaRT NO. DESCRIPTION QTY
*SEE PAGE VI FOR INDIVIDUAL COMPONENTS IN ASSEMBLY
008110 SMaLL SILVER DIE CUT DECaL 2
008130 LICENSE PLaTE FRaME, VORTECH 1
008341 VORTECH CHaRGE COOLER DECaL 1
008447 1 YR S/C STRT INFO PKG aSY VOR 1
009035 S/C LUbE, bOTTLED, VORT 3-PaCK 1
2a046-106 bELT PREMIUM 104.5”, GaTES 1
2F329-134 V3 S/C aSY, 2011 6.4L HEMI CHa 1
4CL020-020 INSTR MaN, ‘11 6.4L HEMI CHaL. 1
4CL010-160 bRKT, FLDYNE CHaLLENGER DRVR 1
4CL010-170 bRKT, FLDYNE CHaLLENGER PaSS 1
4CL110-070 *PWR STEERING aSSY, 6.4L HEMI 1
4CL110-084* S/C MTG bRKT aSY,11-12 HEMI a6 1
4CL110-110
aSSY, DaMPER PIN, HEMI 1
4GR010-110 GUIDE, DWL PIN INST 1
7C014-095 M14-1.5 X 95MM SHCS 1
7U250-019 DOWEL PIN, 1/4X1/2 +.001” 1
7U250-026 DRILL BUSHING, 1/4 ID, 3/8 OD, 1/2L 1
4CL112-084 aIR DISCH aSSY, 11-12 6.4L HEMI 1
4CL010-270 BRKT, DUCT SUPRT, P. SIDE, 6.4 1
4CL010-300 BRKT, DUCT SUPRT, REAR, 6.4 1
4CL012-074 DISCHARGE DUCT “A” COATED 1
4CL012-084 DISCHARGE DUCT “B” COATED 1
4CL012-094 DISCH TUBE “C”, 2011-12 6.4L H 1
7P750-502 REDUCER, 3/4” TO 1/2” COUPLER 1
7PS275-100 SLEEVE, BLACK, 2.750D X 1.0 1
7PS275-300 SLEEVE, BLACK, 2.75ID X 3.0 3
7PS350-277 ELBOW, SIL, 3.5X2.75 90º, BLK 1
7P375-156 3/8 X 3/8 X 5/32 MALE BARB TEE 1
7R002-016 #16 SAE TYPE F SS HOSE CLAMP 2
7R002-044 #44 SAE TYPE F SS HOSE CLAMP 9
7R002-056 #56 SAE TYPE F SS HOSE CLAMP 1
7U030-046 5/32” VACUUM LINE 5’
7U034-016 1” GS HEATER HOSE .25’
8D001-004 COMPRESS BYPASS VALVE, G2 1
8H040-075 FILTER, 1” BYPASS VALVE 1
4CL112-030 aIR INLET aSSY, HEMI CHaL 1
4CL010-180 BRKT, CHALLENGER AIR INLET 1
4CL012-030 DUCT, INLET 08 HEMI CHALLENGER 1
7A250-039 1/4-20 X 3/8” SHCS ZINC PLTD 2
7J250-001 1/4 WASHER, SAE, PLTD 2
7R002-056 #56 SAE TYPE F SS HOSE CLAMP 1
7R002-080 #80 SAE TYPE F SS HOSE CLAMP 1
7S500-351 INLET SLEEVE, HEMI, 5 X 3.5 1
8H040-235 AIR FILTER, 4” FLG X 7.0L 1
7P500-009 1/2”X90 HOSE BARB UNION 1
7U030-036 1/2” OIL DRAIN HOSE 4’
8H040-300 AIR FILTER 300C 1
7U032-020 3/8 P/S HOSE 32”
5W001-093 HaRNESS EXTENSION, ETC, 2011 1
8N006-020 WaTER COOLR, FLDYN DUaL PaSS 1
8N105-220 WaTER TaNK aSSY, 2011 6.4 HEMI 1
4CL010-190 BRKT, CAC TANK, HEMI 1
7A250-050 1/4-20 X .50 SHCS GR8 ZINC PLT 4
7A250-051 1/4-20 X .50 HHCS GR5 ZINC PLT 2
7A250-101 1/4-20 X 1 HHCS ZINC PLTD 1
7E010-075 #12 X 3/4” SHT METL SCRW HEX 8
7J250-001 1/4 WASHER, SAE, PLTD 7
7P375-075 3/4” HOSE BARB UNION, BRASS 5
7P500-026 1/2NPT X 3/4 BARB 90º BRASS 2
7P500-075 1/2NPT X 3/4 HOSE FIT STRT NIC 5
7R007-001 NYLON RATCHET CLAMP 1-1/8” 19
7U038-000 3/4” HEATER HOSE 9’
7U038-012 HOSE, 3/4 DIA 90º, 4 X 12 LEGS 5
7U038-150 HOSE, 3/4 D X 150º MOLDED HOSE 1
7U100-044 TIE WRAP, 4” NYLON 10
7U100-055 TIE WRAP, 7.5” NYLON 10
8N055-030 TANK, WATER TRIANGLE SHAPE 1
8N055-050 PLASTIC CAP, SURGE TANK 1
7P500-034 1/2NPT X 3/4 BARB 90º, NICKEL 2
7P500-035 FITTING, 1/2 NPT X 3/4 BARB X 2
4CL010-290 BRKT, SURGE TANK, FILL ’11 6.4 1
8N056-060 SURGE TANK, PLASTIC 1
7F375-016 3/8-16 HX NUT 1
2A017-881-01 SPACER, .875 OD X .532 LONG 1
7J375-044 3/8 SAE WASHER, PLTD 2
7A375-350 3/8-16 X 3.5” HX HD GR5 1
4CL010-280 MTG BRKT, CAC, 2011 6.4 HEMI 1
4CL010-160 BRKT, FLDYNE CHALLENGER DR 1
4CL010-170 BRKT, FLDYNE CHALLENGER PA 1
8N107-190 WaTER PUMP MTG aSSY, 07 CHGR 1
5W001-011 16-14 GA RING TERM .26” HOLE 1
5W001-013 14-16 GA BUTT CONN BLU INSUL 2
5W001-024 MINI ATC FUSE TAP 1
5W001-025 FEMALE SLIDE,INSULATED,MINI 1
5W001-054 18 GA FUSE HOLDER 1
5W014-030 14GA STRD WIRE BLACK 5
7R003-027 ADEL CLAMP,1-11/16” 1
8F001-402 PUMP, WATER, PIERBURG 1
8N100-001 NYLON MOUNTING KIT 1
8N201-394 WELDED,CORE aSSEMbLY,HEMI 1
