Spectrum Controls 140 AUI 040 00sc - Manual (Page 47)

16-Channel Universal Analog Input Module
49
1.1B Table - Thermocouple Accuracy
Table 2 Thermocouple Accuracy per temperature range below shows the accuracy of thermocouple inputs over a range of tempera-
tures
.
Table 2 Thermocouple Accuracy per temperature range
Range 1 (deg C) Range 2 (deg C) Range 3 (deg C) typ/max CJC accuracy
TC Range Spec Range Spec Range Spec
J -100 to +760 1.1 -200 to -100 2.5 typ 0.7 deg C
K -100 to 1370 1.2 -200 to -100 2 -270 to -200 19 typ 0.7 deg C
T -100 to 400 1.6 -200 to -100 5.8 -270 to -200 15.5 typ 0.7 deg C
E -100 to 1000 1.2 -200 to -100 5.5 -270 to -200 14.5 typ 0.7 deg C
R 0 to 1768 2.3 typ 0.7 deg C
S 0 to 1768 3.5 typ 0.7 deg C
B 600 to 1820 2.2 300 to 600 2.2 typ 10 deg C
N 0 to 1300 0.9 typ 0.7 deg C
J -100 to +760 2.1 -210 to -100 4.8 max 1.25 deg C
K -100 to 1370 3.0 -200 to -100 4.8 -270 to -200 24 max 1.25 deg C
T -100 to 400 2.8 -200 to -100 10 -270 to -200 20 max 1.25 deg C
E -100 to 1000 2.2 -200 to -100 10 -270 to -200 18.5 max 1.25 deg C
R 0 to 1768 5.6 max 1.25 deg C
S 0 to 1768 5.6 max 1.25 deg C
B 600 to 1820 4.6 300 to 600 10.8 max 40 deg C
N 0 to 1300 2.3 max 1.25 deg C
1.1B Table - RTD Accuracy
RTD Type Resistance (
Ω
) Range (deg C) Range (deg F) Typical Max
Acc. (deg C) Error (deg C)
RTD 385 Alpha 100 -200 to +850 -328 to +1562 0.5 1.6
RTD 385 Alpha 200 -200 to +850 -328 to +1382 0.5 1.6
RTD 385 Alpha 500 -200 to +850 -328 to +1562 0.5 1.6
RTD 385 Alpha 1000 -200 to +850 -328 to +1562 0.5 1.6
RTD 3916 Alpha 100 -200 to +630 -328 to +1166 0.4 1.3
RTD 3916 Alpha 200 -200 to +630 -328 to +1166 0.4 1.3
RTD 3916 Alpha 500 -200 to +630 -328 to +1166 0.4 1.3
RTD 3916 Alpha 1000 -200 to +630 -328 to +1166 0.4 1.3
RTD Nickel 618 100 -60 to +180 -76 to +356 0.2 0.6
RTD Nickel 618 200 -60 to +180 -76 to +356 0.2 0.6
RTD Nickel 618 500 -60 to +180 -76 to +356 0.2 0.6
RTD Nickel 618 1000 -60 to +180 -76 to +356 0.2 0.6
RTD Copper 426 10 -100 to +260 -148 to +500 0.3 0.9
RTD Nickel 672 120 -80 to +260 -112 to +500 0.2 0.6
RTD Nickel/Iron 518/604 -100 to +200 -148 to +392 0.2 0.6
