3-14 Point IO™ 4 Channel Universal Analog Input Module
User’s Manual Pub. 0300266-01 Rev. A
ignored. It is recommended to configure both channels identically (0 and 1, 2
and 3) when using multi‐wire RTD. This reduces confusion in the setup. A zero
will be reported for the adjacent odd channel in multi‐wire RTD. The +/‐10V
range is the default input type for each channel.
Data Format (Bits 11 and 12)
Data Format dictates how the data is presented. Engineering Units X1 is the
default.
Table 3-3 (Data Formats)
Input Range Input Value Condition EU x1 EU x10 Raw Prop PID
E Type TC
1000.00 deg C High Limit 10000 1000 32767 16383
1000.00 deg C High Range 10000 1000 32767 16383
-270.00 deg C Low Range -2700 -270 -32768 0
-270.00 deg C Low Limit -2700 -270 -32768 0
J Type TC
1200.00 deg C High Limit 12000 1200 32767 16383
1200.00 deg C High Range 12000 1200 32767 16383
-210.00 deg C Low Range -2100 -210 -32768 0
-210.00 deg C Low Limit -2100 -210 -32768 0
K Type TC
1370.00 deg C High Limit 13700 1370 32767 16383
1370.00 deg C High Range 13700 1370 32767 16383
-270.00 deg C Low Range -2700 -270 -32768 0
-270.00 deg C Low Limit -2700 -270 -32768 0
T Type TC
400.00 deg C High Limit 4000 400 32767 16383
400.00 deg C High Range 4000 400 32767 16383
-270.00 deg C Low Range -2700 -270 -32768 0
-270.00 deg C Low Limit -2700 -270 -32768 0
RTD
100 Ohm Pt 0.385
850.00 deg C High Limit 8500 850 32767 16383
850.00 deg C High Range 8500 850 32767 16383
-200.00 deg C Low Range -2000 -200 -32768 0
-200.00 deg C Low Limit -2000 -200 -32768 0
RTD
1000 Ohm Pt 0.385
850.00 deg C High Limit 8500 850 32767 16383
850.00 deg C High Range 8500 850 32767 16383
-200.00 deg C Low Range -2000 -200 -32768 0
-200.00 deg C Low Limit -2000 -200 -32768 0
RTD
100 Ohm Pt 0.392
630.00 deg C High Limit 6300 630 32767 16383
630.00 deg C High Range 6300 630 32767 16383
-200.00 deg C Low Range -2000 -200 -32768 0
-200.00 deg C Low Limit -2000 -200 -32768 0
RTD
1000 Ohm Pt 0.392
630.00 deg C High Limit 6300 630 32767 16383
630.00 deg C High Range 6300 630 32767 16383
-200.00 deg C Low Range -2000 -200 -32768 0
-200.00 deg C Low Limit -2000 -200 -32768 0
Resistance 3000.00 ohms High Limit 30000 3000 32767 16383
