Form 279 (02.13) ©SOR Inc.

9/12

Linear = mm/inches

Drawing 0090112

Dimensions are for reference only. Contact the factory for certified drawings for a particular model number.

Housing Designator: TA

Piston Number: 13, 14, 16

Conventional Explosion Proof

Linear = mm/inches

Drawing 0090156

Housing Designator: SC

Piston Number: 13, 14, 16

Conventional Explosion Proof

142.9

5.63

71.4

2.81

MOUNTING

HOLE (TYP 4)

7.1

0.28

*65.0

2.56

*119.0

4.68

*234.8

9.24

A

54.0

2.13

(TYP)

108.0

4.25

(TYP)

8.7

0.34

34.0

1.34

106.4

4.19

ELECTRICAL

CONNECTION

3/4 NPT(F)(STD)

1/2 NPT(F)(OPT)

OR PLUGGED(OPT)

(TYP 2)

1/4 OR 1/2 NPT

MALE PROCESS CONNECTION

(OPTIONAL: HI, LO OR BOTH)

PROCESS

CONNECTION

(LOW)

PROCESS

CONNECTION

(HIGH)

LENGTH A

29.7

1/4 NPT(M) =

(SHOWN)

1.17

38.9

1/2 NPT(M) = 1.53
