CHARGING OF NICD/NIMH BATTERY
CHARGING OF NICD/NIMH BATTERY
This program is for charging of NiCd/NiMH
batteries associated with R/C models
applications. You can press START/ENTER
key to make it blink and then INC or DEC to
change the parameter value. Press
START/ENTER key to store the value.
NIMH CHARGE Aut
CUR LIMIT 5.0A
INC DEC
- +
INC DEC
- +
Batt type
Stop
Start
Enter ‘>3 seconds’
The screen shows the real-time status.
Press BATT TYPE/STOP key to end the
program. The sound will emitted to indicates
the end of program.
NIMH 2.0A 7.42V
CHG 022:45 00890
Battery
type
Elapsed
time
Charge current
Battery
voltage
Charged capacity
This program charge the battery using the current you set up. In the
“auto” state, you should set up the upper limit of the charge current to
avoid damage by excessive feeding current. Some batteries of low
resistance and capacity can lead to higher current in the “auto”
charging mode. But in the manual mode, it will charge with the
current you set. You can make it blink in the current field and press
INC and DEC simultaneously to swap between Auto and Manual
Mode. NOTE: Allowable fast charge current: 1C-2C
CHARGING NICD/NIMH BATTERY IN THE CHARGE MODE
DISCHARGE OF NICD/NIMH BATTERY
Set charge current on the left and the final
voltage on the right. Range of the charge
current is 0.1-1.0A; range of final voltage is
0.1-25.0V. Press START/ENTER key for
more than 3 seconds to start the program.
NIMH DISCHARGE
1.0A 11.5A
INC DEC
- +
INC DEC
- +
Batt type
Stop
Start
Enter ‘>3 seconds’
The screen indicates the discharging state.
You can press START/ENTER key to alter
discharge current. Press START/ENTER
again to store the value. Press BATT
TYPE/STOP key to stop discharging. The
emitted sound alerts the end of discharging.
NIMH 1.0A 7.42V
DSC 022:45 00890
Battery
type
Elapsed
time
Discharge
current
Battery
voltage
Discharged
capacity
