- 16 -
CHARGING LITHIUM BATTERY IN THE CHARGE MODE
CHARGING LITHIUM BATTERY IN THE CHARGE MODE
This charging mode is for charging Li-Po/Ion/Fe battery without
balance lead.
The left side of the first line shows the type
of battery you choose. The value on the left
of the second line of the charger is current
user set, After setting the current and
voltage, press START/ENTER key for more
than 3 seconds to start the process.(charge
current: 0.1-5.0A, voltage: 3.7-22.2V).
BALANCE CHARGING OF LITHIUM BATTERY
LiPo BALANCE
2.0A 11.1V(3S)
INC DEC
- +
INC DEC
- +
Batt type
Stop
Start
Enter
Start
Enter
‘>3 seconds’
This displays the number of cells you set up
and the processor detects.”R” shows the
number of cells detected by the charger
and “S” is the number of cells set by you at
the previous screen. If both numbers are
identical you can start charging by press
START/ENTER button. If not, press BATT
TYPE/STOP button to go back to previous
screen to carefully check the number of cells
of the battery pack before going ahead.
R:3SER S:3SER
CONFIRM(ENTER)
This screen shows the real-time status
during charge process. Press BATT TYPE/
STOP key once to stop the charge process.
Li3s 1.2A 12.59V
BAL 022:43 00682
Number
of cells
Charging
time
Charging
current
Battery
voltage
Charged
capacity
This function is for balancing the voltage of Lithium-polymer battery
cells while charging. In the balance mode, the battery needs to have
a balance lead to connect to the individual balance port at the right
side of the charger. And you need to connect the battery's power lead
to the output of charger.
Charging in this mode is different from the normal modes, because
the built-in processor monitors voltage of individual cell and control
input current fed into each cell to equalized voltage of individual cell.
CHARGING LITHIUM BATTERY IN THE BALANCE MODE
